High Frequency Transformers – EE Series
The EE series PCB surface mount transformers (PCB transformers) include the following models: EE6.3, EE8.3, EE10, ZEE13, EE16, EE22, and EE25. A transformer is an electrical device that uses electromagnetic induction to transfer energy between two or more circuits. A changing current in the primary winding of a transformer generates a changing magnetic flux in the iron core, thus producing a changing magnetic field in the secondary winding. We offer high-quality products at the best prices. Our transformers feature superior quality, high precision, reliable performance, and long service life. High-frequency transformers are widely used in electronic equipment such as telecommunications, switching power supplies, AC-DC and DC-DC converters. Therefore, the quality and design of high-frequency transformers are crucial for avoiding failures and damage. If you are looking for transformers, please feel free to contact us! We will provide you with the best after-sales service and fast delivery.
Minimum order quantity: 1 piece
Supply capacity: 1,000,000 pieces per month
Description
Features
- High transmission power, low loss.
- ROHS, Halogen and REACH Compliance.
- Wide frequency range, stable performance, low temperature rise.
Applications
- Used in transmitters, computers, communication equipment, televisions.
- Electronic instruments and equipment, aircraft, etc.
Shape and Dimensions
| Dielectric srength | Impedance (mH) | Dimension L*W*H (mm) | Rated Current (A) |
| EE6.3 | 0.2-5 | 7.8*7.8*8.2 | 0.1-0.6 |
| EE8.3 | 0.3-20 | 10.0*10.0*10.0 | 0.2-1.0 |
| EE10 | 0.5-50 | 12.5*12.5*13.0 | 0.2-1.5 |
| EE13 | 0.5-15 | 15.5*14.5*15 | 0.5-2.0 |
| EE16 | 0.5-25 | 18.0*14.5*17.0 | 0.5-2.0 |
| EE16 | 0.5-20 | 19.0*19.5*17.5 | 0.5-3.0 |
| EE16 | 0.5-20 | 20.5*17.5*20.0 | 0.5-3.0 |
| EE22 | 0.5-25 | 23.5*17.5*20.0 | 0.5-3.5 |
| EE25 | 0.5-30 | 26.5*18.5*23.5 | 0.5-4.0 |
Certification: REACH, ROSH, ISO9001, ISO14001，
Packing: Tape and Reel
Delivery date: 7-20days (most can finish within 1 week if urgent needed)
MOQ: 1 unit
Payment Term: T/T, L/C or others for negotiation.
Free Sample Services: usually take 3-5 working days after customs need them.
EE Series High Frequency Transformer
Detailed informations including inductance, tolerance, rated current and DCR.
